CPT TRUCKS


Vertek’s cone penetration testing (CPT) trucks offer deeper soundings, a safe controlled environment, and high production.

SEE THE HEAVYWEIGHT CPT TRUCK IN ACTION


ARE YOU READY TO TAKE YOUR CPT OPERATIONS TO THE NEXT LEVEL?

Vertek’s CPT trucks can be designed to be mounted to the chassis of your choice, from a heavy-duty pick-up truck to a 6×6 chassis to reach offroad environments. We build our CPT trucks to maximize workspace and storage, optimize the user experience, and ergonomically organize tools, outlets, and cabinets for maximum productivity.

Our built-in and automated seismic hammer is integrated into the rapid hydraulic leveling system to expedite setup time-on-site and for unmatched shear wave generation. This, coupled with the weight of the vehicle, enables soundings to greater depths while completing seismic and dissipation test without interruption.

Typically, 100-foot soundings are completed in less than one hour, easily collecting over 500’ of penetration per day. Based on field experience, our interior layout provides a mobile laboratory feel, ample workspace, and climate-controlled with plenty of room for your crew and customer. Vertek can customize your workspace to meet your needs, such as options for grouting, cupolas, side doors, water tanks, sinks, etc.

We design and build to your specifications.

LIGHTWEIGHT CPT TRUCK


Offering 10 to 20 tons of push force with anchoring capabilities, Vertek’s Lightweight cone penetration testing (CPT) Trucks are perfect for hard to reach areas and jobs requiring deep sediment penetration.

SEE THE LIGHTWEIGHT CPT TRUCK IN ACTION


SYSTEM FEATURES


Download the Heavyweight and Lightweight product brochure here and here, respectively.

CPT push specifications

  • 20 ton push capacity
  • 25 ton pull capacity
  • 42 inch cylinder stroke

Hydraulic clamp

  • Heat treated smooth jaws that won’t scar the rods.
  • 85,000 lbs of clamping force
  • Visible pressure gauge for verification.

Regenerative circuit

  • Custom hydraulic manifold to decrease non-ASTM cycle times.
  • Automatically comes out of regenerative mode for higher retraction loads.

Non-retractable guide tube

  • Provides lateral support for rods while pushing.
  • Threaded for installation of rod wiper or steam cleaning heads.

Electronic hydraulic controls

  • User intuitive push button HMI
  • Independent joystick for manual operation.
  • Highly visible hydraulic pressure gauges for system operation.

Safety clamp

  • Secondary hydraulic rod clamp to hold rods when the primary clamp is released.
  • Visible pressure gauge for verification.

CUSTOMERS


customers of vertek cpt trucks

OUR COMMITMENT


When you purchase a piece of Vertek CPT equipment, you become part of Team Vertek. We provide every customer with unparalleled customer service and unlimited technical support. From helping you choose the best solution for your business to training and field support, we will be by your side and always just a phone call away.

CONTACT US


Give us a call at 1-800-639-6315 or send us a note and we will follow up to discuss your needs and our solutions.
