DRILL RIG
CONVERSION
KIT

It’s never been easier to add cone penetration testing (CPT) services.

SEE IT IN ACTION

WANT TO GROW BUSINESS OUTSIDE OF SPT AND HOLLOW STEM AUGER DRILLING?

Simply install Vertek’s turnkey Drill Rig Conversion Kit to your drill rig and let the revenue roll in.

The Drill Rig Conversion Kit allows drilling service providers conducting geotechnical site characterization activities to easily conduct CPT with existing drilling equipment.

A simple adapter screwed on to the drill head allows the existing push and pull hydraulic system to manually advance and retract the CPT equipment to desired subsurface depth safely, and with control.

If you’re considering the growth of your drilling business and providing additional capabilities to your customers, Vertek’s Drill Rig Conversion Kit is the best and most cost-effective option to enter the CPT service marketplace.

EASY CONVERSION

In less than 10 minutes, you will be ready to conduct CPT soundings.

  • Vertek offers drill head adapters for use with VTK or HT Series cones and for both 10cm2 or 15cm2 cones.
  • Customizable for either pin or box drill heads and different thread types (ex. NWJ, AWJ, etc.).
  • Depth can be measured with a ground-based encoder via wheel system or string pot transducer.
  • Shear wave seismics can be conducted using our triggering system, steel plate placed under the drill rig jack, and sledgehammer.
  • Rod rack system available to secure the rods and protect the umbilical cable. String rods in the rear of a vehicle for the desired depth of exploration if not using a rod rack.
  • Two drill rig interfaces offer push & pull capabilities including a push cap for advancing and a slotted threaded adapter rod for retracting. The original four-piece system relies on threads for connection while the three-piece system features a latch for retraction.

KIT OPTIONS

Download the product brochure here.

FAQs

How is the Drill Rig Conversion Kit mounted?

The Drill Rig adapter has a threaded female end with NWJ threads. If requested, we can modify this to your specific thread connection needs. It simply screws on by hand and includes a push cap and pull cap to place on the rods being pushed into and extracted from the ground.

Do I need to anchor my drill rig down when doing CPT?

It is best practice to anchor one flight of augers to ensure you have maximum push force, especially when pushing through dense sediments. We recommend checking with your drill rig manufacturer to determine the most appropriate way to anchor to augers.

Which drill rig manufacturers is the Drill Rig Conversion Kit compatible with?

The Drill Rig Conversion Kit can be used on virtually any drill rig with a static push/pull hydraulic mast. It is currently fielded by operators using Central Mine Equipment Company, Mobile Drill International, Acker Drill Company, Diedrich Drilling Inc, and others.

What power supply do I need for the Data Acquisition System?

You need access to a 110v power source, ideally a pure sine wave inverter. If your drill rig does not have a power supply, a small generator is recommended.

How many people are required to operate the Drill Rig Conversion Kit?

It only takes two people to conduct CPT soundings.

Can you push through rock?

If you find that you must push through solid rock, you will need to core the rock and continue your CPT sounding through the cored hole. The CPT software allows you to pause a test, complete the coring, and resume the test with the new depth documented.

CONVERSION KIT CUSTOMERS

Drill Rig

OUR COMMITMENT

When you purchase a piece of Vertek CPT equipment, you become part of Team Vertek. We provide every customer with unparalleled customer service and unlimited technical support. From helping you choose the best solution for your business to training and field support, we will be by your side and always just a phone call away.
